Μάρκα:
Greef
Πιστοποίηση:
CE
Model Number:
TYP
TYP Magnet motors incorporate rotors equipped with permanent magnets. This design enhances the overall performance of the motor by delivering several key benefits.
One of the primary advantages of this technology is its ability to achieve higher efficiency. Additionally, these motors offer a greater power density relative to their frame size, making them more compact yet powerful.
These motors are controlled using frequency inverters, which ensure a consistent torque output throughout a broad range of speeds. They maintain high efficiency even at lower speeds, outperforming traditional induction motors without the need for forced ventilation.
The W21 Magnet motors are specifically designed to operate at low speeds while producing minimal noise. Furthermore, they contribute to energy savings, making them an environmentally friendly choice for various applications.
This motor saves up to 30% energy compared to induction motors driven by inverters. It operates with high efficiency over a broad load range, from 20% to 110% of its rated load. Energy savings have been measured to range between 10% and 40%, ensuring substantial reduction in power consumption.
Additionally, it achieves an exceptionally high power factor, close to 1.0 at rated conditions and never below 0.95, which helps reduce stator current and copper losses significantly.
The motor delivers constant torque over a wide range of speeds without the need for forced ventilation. This makes it ideal for applications that require variable speed yet consistent torque, even at low speeds. Importantly, it operates effectively without the need for an encoder.
Bearings used in this motor offer an L10 life rating of up to 100,000 hours, which translates to more than 10 years of continuous operation. The design includes grease nipples for easy re-lubrication, helping to minimize maintenance stoppages and enhance reliability.
Powerful NdFeB (Neodymium/Iron/Boron) rare-earth magnets are utilized, providing magnetic strength approximately 18 times greater than traditional ferrite magnets. These magnets are coated with a protective epoxy layer, delivering superior mechanical strength and excellent corrosion resistance.
Embedded PTC (Positive Temperature Coefficient) thermistors within the windings offer comprehensive protection against overheating caused by phase loss, overloads, or under/over voltage conditions. This ensures dependable and safe motor operation.
As a synchronous motor, the rotor speed is perfectly synchronized with the rotating magnetic field of the stator, eliminating slip and rotor power loss. The speed remains stable regardless of voltage fluctuations or changes in load, greatly improving control accuracy.
The motor employs a maximum torque/current ratio control mode, maintaining a high power factor throughout its entire speed range. This feature substantially reduces stator current by 15% to 30%, which in turn decreases cable transmission losses and increases the effective capacity of cables.
Owing to its high efficiency and low losses, the motor experiences a temperature rise that is 15 to 20°C lower than comparable asynchronous motors under the same conditions, which contributes to longer equipment life and reliability.
The motor is widely applied across various industries including injection molding machines, air compressors, pipe making equipment, hydraulic machinery, food processing machines, extruders, wire drawing machines, and pharmaceutical equipment. It must be used alongside a dedicated permanent magnet motor inverter for optimal performance.
By replacing a 37kW IE2 (GB3) induction motor with this motor, energy costs can be reduced by approximately 9,000 RMB annually based on continuous 24/7 operation, making it a financially advantageous choice.
The TYP series high-efficiency permanent magnet frequency conversion synchronous motors are highly versatile and find extensive applications across various industries. These advanced motors are designed to provide reliable and efficient performance, making them an ideal choice for numerous mechanical systems.
They are commonly utilized in injection molding machines, where precise control and energy savings are crucial. Additionally, these motors play a significant role in air compressors, ensuring stable and effective operation under different conditions.
Beyond that, the TYP series motors are also employed in pipe making equipment, hydraulic machinery, and food processing machines. Their adaptability allows them to meet the rigorous demands of cement pipe manufacturing, plastic extrusion, wire drawing, and pharmaceutical equipment production as well.
Overall, the TYP series motors offer a robust and efficient solution for a wide range of industrial applications, contributing to improved productivity and energy efficiency.
Greef offers customizable Permanent Magnet Motor solutions with the model number TYP, originating from China. Our Synchronous Magnet Motor is designed as a 3-phase AC Synchronous Motor with 6 poles, operating at a frequency of 50/60HZ and classified with an IP54 degree of protection. This Brushless Permanent Magnet Motor features an insulation grade of H, ensuring durability and reliable performance.
We provide flexible customization options for low-speed applications, allowing you to tailor the motor to your specific requirements. Each order has a minimum quantity of 1 set, with pricing negotiable to meet your budget needs. All products are CE certified, guaranteeing high standards of quality and safety.
Packaging is handled with care using foam and plywood cases to ensure safe delivery. The typical delivery time is 25 working days. Payment terms include T/T, Western Union, MoneyGram, and L/C, facilitating convenient transactions. Greef maintains a strong supply ability to meet your demand efficiently.
Product Packaging and Shipping
Our Permanent Magnet Motors are carefully packaged to ensure safe delivery and optimal protection during transit. Each motor is securely wrapped with protective materials to prevent damage from shocks, vibrations, and moisture.
The motors are placed in sturdy, custom-designed cartons that provide cushioning and support. For bulk orders, the cartons are further packed into reinforced crates or pallets to facilitate handling and shipping.
We offer multiple shipping options including air freight, sea freight, and express courier services to meet your delivery requirements. All shipments are tracked and insured to guarantee timely and secure arrival.
Before shipping, each Permanent Magnet Motor undergoes a thorough inspection and testing to ensure it meets quality standards. Relevant documentation such as certificates of conformity, packing lists, and invoices are included with each shipment.
Please contact our sales team for special packaging requests or customized shipping solutions.
